Product Description
Hydac 705843 Hydraulic Check Valve Rv-20-01.X/12
Next Day Fittings is an authorized Hydac distributorAs an official Hydac distributor, Next Day Fittings delivers our customers the best pricing and factory lead times. Our trained and knowledgeable staff is always ready to help with any aspect of the Hydac Hydraulic Check Valves product purchasing process. Whether you need assistance from a customer service agent or a product engineering expert, Next Day Fittings is committed to being your Hydac Hydraulic Check Valves partner every step of the way.Hydac 705843 Hydraulic Check Valve Rv-20-01.X/12Manufacturer:HydacManufacturer Part Number:705843| Type | Flow Control Valve |
| Series | RV Series Check Valves |
| Size | 20 |
| Mounting Type | Inline Mounting |
| Connection Type | SAE - SAEJ1926 Ports with ISO 725, SAE Threads and O-Ring Sealing |
| Material | Carbon Steel |
| Operating Temperature [Max] | 212 °F |
| Operating Temperature [Min] | -4 °F |
| Nominal Flow | 150 gpm |
| Operating Pressure [Max] | 345 bar 5000 psi |
| Cracking Pressure | 0.5 bar 7 psi |
| Viscosity | 335 SUS |
| Thread Type | SAE |
| Thread Size | 1 5/16-12 UN |
| Thread Type 2 | SAE |
| Thread Size 2 | 1 5/16-12 UN |
| Industry Standards/Certifications | International Organization for Standardization (ISO) |
| Length | 5" 127 mm |
| Hex Size | 1 13/16" 46 mm |
| Weight | 0.22 lb 0.1 kg |
| Additional Information/Notes | Not recommended for high-cycle applications! Pressure Drop curves were established by using mineral oil with kinematic viscosity 335 SUS at 86 °F / 30 °C. Dimensions are for general information only, all critical dimensions should be verified by requesting a certified print. |
