Product Description
Bosch Rexroth R901555492 Hydraulic Directional Control Valves 4WE6T6X/EG24NK40/Z/62SO43A-1872-A
Next Day Fittings is an authorized Bosch Rexroth distributor. If you have any questions about this product or it's availability, please call us at: 844-323-8752Bosch Rexroth industrial hydraulics solutions are crafted to conquer the most challenging conditions. Bosch Rexroth is synonymous with exceptional performance, steadfast reliability, and precise accuracy in the industrial hydraulics sector. Next Day Fittings takes pride in delivering Bosch Rexroth's top-tier hydraulics technology tailored for the rigorous demands of heavy-duty industries.4-way (4/3) directional control hydraulic direct-acting double solenoid valve (32gpm) with concealed manual override - circuit diagram J73 - smooth switching - Bosch Rexroth (WE series size 10 / component series 3X) - 4WE 10 J73-3X/CG12N9K4 - 12Vdc - 315bar / 4569psi - 3-pin DIN connector - NBR seals - Mounting on subplate (Porting pattern according to ISO 4401-05-04-0-05) - IP65 - 4-ports 3-positions - high-power wet-pin solenoid (with detachable coil) - mech. spring center - equivalent to 4WE10J73-3X/CG12N9K4 / 4WE10J733XCG12N9K4R978032338 Bosch Rexroth Hydraulic direct-acting double solenoid valve - 4WE10J733XCG12N9K4
Directional spool valves, direct operated, with solenoid actuation ? Type WE
Type WE hydraulic directional valves are heavy-duty, solenoid actuated, direct operated spool valves. They control the start, stop, and direction of a flow. These directional valves basically consist of the housing; one or two electronic solenoids, the control spool; and are available with or without return springs or detents. A full array of spools are possible with variations in voltage and electrical connection, all within the program. Flow and pressure rates available to cover a wide range of applications.
Features:
- Size 10
- Component Series 5X
- Max Operating Pressure 350 bar
- Max flow 160 l/min - DC, 120 l/min - AC
- 4/3, 4/2 or 3/2 way versions
- Porting Pattern according to ISO 4401-05-04-0-05
- High-power solenoid, optionally rotatable by 90°
- Electrical connection as individual or central connection
- Cartridge optionally equipped with PWM connector (fast switching amplifier, enerty reduction)
- Manual Override - optional
- CE conformity according to the Low-Voltage Directive 2014/35/EU for electrical voltages > 50 VAC or > 75 VDC
- Solenoid coil as approved component with UR marking - optional
- Approval according to CSA C22.2 no. 139-13 - optional
Product | Bosch Rexroth Hydraulic direct-acting double solenoid valve |
Model Code | 4WE10J73-3X/CG12N9K4 |
Series / Family | WE series - size 10 / component series 3X |
Valve Function | 4/3-way (4 ports / 3 positions), Double solenoid, Monostable |
Max. Flow | 120L/min |
Max Operating Pressure | 315bar |
Hydraulic Fluid Temperature Range | −30°C…+80°C |
Ambient Temperature Range | −30°C…+50°C |
Reset Method | Mechanical Spring |
Manual Override | Flush / Concealed |
Solenoid | High-Power Wet-Pin with Detachable Coil |
Seal Material | NBR |
Connection Type | 3-pin DIN connector (43650) |
Mounting Mode | Porting pattern according to ISO 4401-05-04-0-05 |
Current Consumption | 3A (nominal hold current) |
Control Voltage (DC) | 12Vdc |
Diagram | circuit diagram J73 |
Protection Class | IP65 |
Additional Info | smooth switching |
Compliant with standard(s) | ISO 4401-05-04-0-05 |
