Product Description
Bosch Rexroth R901407601 Hydraulic Direct-Acting Single Solenoid Valve 3WE10A5X/EG24N9K72L/M
Next Day Fittings is an authorized Bosch Rexroth distributor. If you have any questions about this product or it's availability, please call us at: 844-323-8752Bosch Rexroth industrial hydraulics solutions are crafted to conquer the most challenging conditions. Bosch Rexroth is synonymous with exceptional performance, steadfast reliability, and precise accuracy in the industrial hydraulics sector. Next Day Fittings takes pride in delivering Bosch Rexroth's top-tier hydraulics technology tailored for the rigorous demands of heavy-duty industries.3WE10A5X/EG24N9K72L/M, 3-way 2-positions (3/2) directional control, mech. spring return single solenoid valve, 24Vdc, NBR seals, 4-pin M12 connector with suppressor diode and D.E.S.I.N.A pin assignment3-way (3/2) directional control hydraulic direct-acting single solenoid valve (42gpm) with concealed manual override - circuit diagram A - Bosch Rexroth (WE series size 10 - E / component series 5X (50...59)) - 3WE 10 A5X/EG24N9K72L/M - 24Vdc solenoid (40W) - 350bar / 5076psi - 4-pin M12 connector with suppressor diode and D.E.S.I.N.A pin assignment - NBR seals - Mounting on subplate (Porting pattern according to ISO 4401-05-04-0-05) - IP65 - 3-ports 2-positions - high-power wet-pin solenoid (with detachable coil) - mech. spring return - equivalent to 3WE10A5X/EG24N9K72L/M / 3WE10A5XEG24N9K72LM| Product | Bosch Rexroth Hydraulic direct-acting single solenoid valve |
| Model Code | 3WE10A5X/EG24N9K72L/M |
| Series / Family | WE series - size 10 - E / component series 5X (50...59) |
| Valve Function | 3/2-way (3 ports / 2 positions), Single solenoid, Monostable |
| Max. Flow | 160L/min 42gallons/min |
| Max Operating Pressure | 350bar 5076psi |
| Hydraulic Fluid Temperature Range | −20°C…+80°C −4°F…+176°F |
| Ambient Temperature Range | −20°C…+70°C −4°F…+158°F |
| Reset Method | Mechanical Spring |
| Manual Override | Flush / Concealed |
| Solenoid | High-Power Wet-Pin with Detachable Coil |
| Seal Material | NBR |
| Connection Type | 4-pin M12 connector with suppressor diode and D.E.S.I.N.A pin assignment |
| Mounting Mode | Porting pattern according to ISO 4401-05-04-0-05 |
| Power Consumption | 40W |
| Current Consumption | 2A (nominal hold current) |
| Control Voltage (DC) | 24Vdc |
| Diagram | circuit diagram A |
| Protection Class | IP65 |
| Compliant with standard(s) | CE ISO 4401-05-04-0-05 |
