Product Description
Bosch Rexroth R900957794 Hydraulic Direct-Acting Double Solenoid Valve 4WE10J73-3X/CG96N9K4/A12V
Next Day Fittings is an authorized Bosch Rexroth distributor. If you have any questions about this product or it's availability, please call us at: 844-323-8752Bosch Rexroth industrial hydraulics solutions are crafted to conquer the most challenging conditions. Bosch Rexroth is synonymous with exceptional performance, steadfast reliability, and precise accuracy in the industrial hydraulics sector. Next Day Fittings takes pride in delivering Bosch Rexroth's top-tier hydraulics technology tailored for the rigorous demands of heavy-duty industries.4WE10J73-3X/CG96N9K4/A12V, 4-way 3-positions (4/3) directional control, mech. spring center double solenoid valve, 100Vac|110Vac, FKM seals, 3-pin DIN connector4-way (4/3) directional control hydraulic direct-acting double solenoid valve (32gpm) with concealed manual override - circuit diagram J73 - smooth switching - Bosch Rexroth (WE series size 10 / component series 3X) - 4WE 10 J73-3X/CG96N9K4/A12V - 96Vdc / 100Vac / 110Vac - 315bar / 4569psi - 3-pin DIN connector - increased switching time with 1.2mm / 0.047" orifice diam. - FKM seals - Mounting on subplate (Porting pattern according to ISO 4401-05-04-0-05) - IP65 - 4-ports 3-positions - high-power wet-pin solenoid (with detachable coil) - mech. spring center - equivalent to 4WE10J73-3X/CG96N9K4/A12V / 4WE10J733XCG96N9K4A12V| Product | Bosch Rexroth Hydraulic direct-acting double solenoid valve |
| Model Code | 4WE10J73-3X/CG96N9K4/A12V |
| Series / Family | WE series - size 10 / component series 3X |
| Valve Function | 4/3-way (4 ports / 3 positions), Double solenoid, Monostable |
| Max. Flow | 120L/min 32gallons/min |
| Max Operating Pressure | 315bar 4569psi |
| Hydraulic Fluid Temperature Range | −20°C…+80°C −4°F…+176°F |
| Ambient Temperature Range | −20°C…+50°C −4°F…+122°F |
| Reset Method | Mechanical Spring |
| Manual Override | Flush / Concealed |
| Solenoid | High-Power Wet-Pin with Detachable Coil |
| Seal Material | FKM |
| Connection Type | 3-pin DIN connector (43650) |
| Mounting Mode | Porting pattern according to ISO 4401-05-04-0-05 |
| Current Consumption | 1A (nominal hold current) |
| Control Voltage (DC) | 96Vdc |
| Control Voltage (AC) | 100Vac / 110Vac (50Hz/60Hz) |
| Diagram | circuit diagram J73 |
| Protection Class | IP65 |
| Additional Info | increased switching time with 1.2mm / 0.047" orifice diam. |
| Compliant with standard(s) | ISO 4401-05-04-0-05 NFPA T3.5.1 R2-2002 D05 |
