Product Description
Bosch Rexroth R900947226 Hydraulic Direct-Acting Double Solenoid Valve 4WE6D73-6X/OFEG24N9K4/A12B12
Next Day Fittings is an authorized Bosch Rexroth distributor. If you have any questions about this product or it's availability, please call us at: 844-323-8752Bosch Rexroth industrial hydraulics solutions are crafted to conquer the most challenging conditions. Bosch Rexroth is synonymous with exceptional performance, steadfast reliability, and precise accuracy in the industrial hydraulics sector. Next Day Fittings takes pride in delivering Bosch Rexroth's top-tier hydraulics technology tailored for the rigorous demands of heavy-duty industries.4WE6D73-6X/OFEG24N9K4/A12B12, 4-way 2-positions (4/2) directional control, mech. detent double solenoid valve, 24Vdc, NBR seals, 3-pin DIN connector4-way (4/2) directional control hydraulic direct-acting double solenoid valve (21gpm) with concealed manual override - circuit diagram D73 - smooth switching - 0.047" diam. throttle insert at port P - Bosch Rexroth (WE series size 6...E / component series 6X (60...69)) - 4WE 6 D73-6X/OFEG24N9K4/A12B12 - 24Vdc solenoid (30W) - 350bar / 5076psi - 3-pin DIN connector - increased switching time with 1.2mm / 0.047" orifice diam. - NBR seals - Mounting on subplate (Porting pattern according to ISO 4401-03-02-0-05 and NFPA T3.5.1 R2-2002 D03) - IP65 - 4-ports 2-positions - high-power wet-pin solenoid (with detachable coil) - mech. detent - equivalent to 4WE6D73-6X/OFEG24N9K4/A12B12 / 4WE6D736XOFEG24N9K4A12B12| Product | Bosch Rexroth Hydraulic direct-acting double solenoid valve |
| Model Code | 4WE6D73-6X/OFEG24N9K4/A12B12 |
| Series / Family | WE series - size 6...E / component series 6X (60...69) |
| Valve Function | 4/2-way (4 ports / 2 positions), Double solenoid, Bistable |
| Max. Flow | 80L/min 21gallons/min |
| Max Operating Pressure | 350bar 5076psi |
| Hydraulic Fluid Temperature Range | −20°C…+80°C −4°F…+176°F |
| Ambient Temperature Range | −20°C…+50°C −4°F…+122°F |
| Reset Method | Mechanical Detent |
| Manual Override | Flush / Concealed |
| Solenoid | High-Power Wet-Pin with Detachable Coil |
| Seal Material | NBR |
| Connection Type | 3-pin DIN connector (43650) |
| Mounting Mode | Mounting on subplate (Porting pattern according to ISO 4401-03-02-0-05 and NFPA T3.5.1 R2-2002 D03) 42mm clamping length with 4 x M5 screws or 4 x 10-24 UNC screws |
| Power Consumption | 30W |
| Current Consumption | 2A (nominal hold current) |
| Control Voltage (DC) | 24Vdc |
| Diagram | circuit diagram D73 |
| Protection Class | IP65 |
| Additional Info | increased switching time with 1.2mm / 0.047" orifice diam. |
| Compliant with standard(s) | CE ISO 4401-03-02-0-05 NFPA T3.5.1 R2-2002 D03 |
