Balluff BOS013H BOS 18M-PA-LD10-S4 Photoelectric Sensors Diffuse
Next Day Fittings is an official Balluff distributor, we can offer our customers the best pricing and factory lead times. Our trained and knowledgeable staff is always ready to help with any aspect of the Balluff product purchasing process. Whether you need assistance from a customer service agent or a product engineering expert, Next Day Fittings is your Balluff partner every step of the way.
Principle of operation | Photoelectric sensor |
Operating principle | Photoelectric |
Principle of optical operation | Diffuse sensor, (energetic) |
Ambient temperature | -10...50 °C |
Beam characteristic | Divergent |
Adjuster | Potentiometer 270° (1x) |
Connection | Connector, M12x1-Male, 4-pin |
Connector design | M12x1 |
Diagnostic coverage | 0 % |
Dimension | ? 18 x 81.5 mm |
Display | Output function- LED YE
LED GN: Power |
Housing material | Brass, nickel-plated |
Interface | PNP Normally open (NO);PNP Normally closed (NC) |
IP rating | IP67 |
Laser class per IEC 60825-1 | 1 |
Light type | Laser Red light |
Material | Brass nickel-plated |
Material sensing surface | PMMA |
Measuring length | 0...350 mm |
Measuring range | 0...350 mm |
Mission Time | 10 a |
Mounting part | Nut M18x1 |
MTTF (40 °C) | 739 a |
Operating voltage max. DC 01 | 30.0 V |
Operating voltage Ub | 10...30 VDC |
Range | 0...350 mm |
Rated operating voltage Ue | 24 VDC |
Rated operating voltage Ue DC | 24 V |
Setting | Rated switching distance (Sn) |
Style Housing | ? 18 mm |
Style | Cylinder;Straight optics |
Surface protection | nickel-plated |
Switching frequency | 1500 Hz |
Switching function | Normally open (NO)
Normally closed (NC) |
Switching function, optical | Light-on
dark-on |
Switching output | PNP Normally closed (NC)
PNP Normally open (NO) Pins 4-2 |
Wave length | 650 nm |
Approval/Conformity | CE, UKCA, cULus, WEEE |
Additional text | Order accessories separately.
For additional information, refer to user&apos
s guide.
Reference object (target): gray card, 200 x 200, 90 % remission, axial approach.
The sensor is functional again after the overload has been eliminated. |
