Balluff BGL0057 Photoelectric Sensor Accessory
Next Day Fittings is an official Balluff distributor, we can offer our customers the best pricing and factory lead times. Our trained and knowledgeable staff is always ready to help with any aspect of the Balluff product purchasing process. Whether you need assistance from a customer service agent or a product engineering expert, Next Day Fittings is your Balluff partner every step of the way. Principle of operation | Photoelectric sensor |
Operating principle | Photoelectric |
Principle of optical operation | Through-beam sensor |
Ambient temperature | -25...55 °C |
Cable | PVC, 1 m |
Cable diameter D | 2.5 mm |
Connection | Cable, 1 m, PVC |
Dimension | 6 x 16 x 13.4 mm |
Fork opening | 5 mm |
Housing material | PBT |
Interface | NPN Normally closed (NC);NPN Normally open (NO) |
IP rating | IP65 |
Light type | LED infrared Infrared |
Material | PBT |
Material jacket | PVC |
Material sensing surface | PMMA |
Mission Time | 10 a |
Mounting part | Through-hole 3.2 mm (2x) |
Number of conductors | 4 |
Operating voltage max. DC 01 | 24 V |
Operating voltage Ub | 5...24 VDC |
Range | 5 mm |
Rated operating voltage Ue | 24 VDC |
Rated operating voltage Ue DC | 24 V |
Style Housing | block style |
Style | Fork |
Switching frequency | 1 kHz |
Switching function | Normally open (NO) |
Switching output | NPN Normally closed (NC) |
Approval/Conformity | CE, cULus, UKCA, WEEE |
Additional text | The sensor is functional again after the overload has been eliminated. |
