Product Description
The Balluff BCC09J2 BCC M415-0000-1A-043-PS0534-150 is a single-ended sensor and actuator cable featuring an M12x1 female connector with 5-pole A-coded configuration and 15 meter length of PUR shielded black cable.
- Connection: M12x1 female, 5-pole, A-coded
- Cable material: PUR shielded black, drag chain compatible
- Cable length: 15.00 m
- Cable diameter: 5.00 mm
- Number of conductors: 5
- Conductor cross-section: 0.34 mm
- Connector type: straight
- Operating voltage: 125.0 V DC maximum
- Temperature range fixed routing: -50 to 80 C
- Temperature range flexible routing: -25 to 80 C
- Temperature range drag chain: -25 to 60 C
- Approvals: CE, cULus LISTED
This industrial-grade cable reliably transmits signals, data, and power in demanding applications. The drag chain compatible design makes it suitable for moving system installations.
