Product Description
Bosch Rexroth R901235116 Hydraulic Directional Control Valves 4WEH10HD4X/OF6EW110N9ETK4/B10
Next Day Fittings is an authorized Bosch Rexroth distributor. If you have any questions about this product or it's availability, please call us at: 844-323-8752Bosch Rexroth industrial hydraulics solutions are crafted to conquer the most challenging conditions. Bosch Rexroth is synonymous with exceptional performance, steadfast reliability, and precise accuracy in the industrial hydraulics sector. Next Day Fittings takes pride in delivering Bosch Rexroth's top-tier hydraulics technology tailored for the rigorous demands of heavy-duty industries.4-way (4/2) directional control hydraulic direct-acting double solenoid valve (16gpm) with concealed manual override - circuit diagram D - Bosch Rexroth (WE series size 6...H / component series 7X) - 4WE 6 D7X/OFHG24N9K4/V - 24Vdc solenoid (26W) - 315bar / 4550psi - 3-pin DIN connector - FKM seals - Mounting on subplate (Porting pattern according to ISO 4401-03-02-0-05 and NFPA T3.5.1 R2-2002 D03) - IP65 - 4-ports 2-positions - standard wet-pin solenoid - mech. detent - equivalent to 4WE6D7X/OFHG24N9K4/V / 4WE6D7XOFHG24N9K4VR901204583 Bosch Rexroth Hydraulic Direct-Acting Double Solenoid Valve - 4WE6D7X/OFHG24N9K4/V
Directional spool valves, direct operated, with solenoid actuation ? Type WE
Type WE hydraulic directional valves are heavy-duty, solenoid actuated, direct operated spool valves. They control the start, stop, and direction of a flow. These directional valves basically consist of the housing; one or two electronic solenoids, the control spool; and are available with or without return springs or detents. A full array of spools are possible with variations in voltage and electrical connection, all within the program. Flow and pressure rates available to cover a wide range of applications. The duty cycle is 100% with switching frequency capability of 15000/hr for DC and 7200/hr for AC.
Features:
- Size 6
- Component Series 7X
- Max Operating Pressure 315 bar
- Max flow 60 l/min
- 4/3, 4/2 or 3/2 way versions
- Porting pattern according to DIN 24340 form A
- Wet-pin DC solenoids
- Rotatable solenoid coil
- The coil can be changed without having to open the pressure-tight chamber
- Electrical connection as individual connection
- Concealed Manual Override
Product | Bosch Rexroth Hydraulic direct-acting double solenoid valve |
Model Code | 4WE6D7X/OFHG24N9K4/V |
Series / Family | WE series - size 6...H / component series 7X |
Valve Function | 4/2-way (4 ports / 2 positions), Double solenoid, Bistable |
Max. Flow | 60L/min |
Max Operating Pressure | 315bar |
Hydraulic Fluid Temperature Range | −30°C…+80°C |
Ambient Temperature Range | −30°C…+50°C |
Reset Method | Mechanical Detent |
Manual Override | Flush / Concealed |
Seal Material | FKM |
Connection Type | 3-pin DIN connector (43650) |
Mounting Mode | Mounting on subplate (Porting pattern according to ISO 4401-03-02-0-05 and NFPA T3.5.1 R2-2002 D03) |
Power Consumption | 26W |
Current Consumption | 2A (nominal hold current) |
Control Voltage (DC) | 24Vdc |
Diagram | circuit diagram D |
Protection Class | IP65 |
Additional Info | standard wet-pin solenoid |
Compliant with standard(s) | DIN 24340 form A |
